The Isuzu D-Max TFR86 Single Cab 4x2 pickup offers flexibility, power and strength to make it unmatched for the different missions of our customers. Agility and tight turning circles make it perfect truck for city centre jobs. It is stable and secure for inter city transport at commercial speeds on highways and it is ready to take on demanding roads with it's robust structure.

Submit your request on our easy form and a member of ACMG Sales Support team will then be in touch to confirm your details and ensure everything is processed quickly and correctly for your Isuzu D-Max Single Cab pickup.

We work with all the major banks and ensure your finance application is seamless with guidance to provide the correct supporting documents ensuring fast turn arounds getting your Isuzu D-Max TFR86 Single Cab pickup on the road.

PICKUP RANGE - SINGLE CAB WORKHORSE

Isuzu D-Max TFR86 Specifications

4x2

Drive Configuration

Single Cab

TFR86 BASE HR (A/C)

Seats Driver and 2 Passengers

100 (134) @ 3,600

Max Output kW (hp) @ rpm

+ Expand / Collapse Selection

Engine

Engine model

4JK1-TC HO

Emission

Euro IV

Type

Diesel 4 Cylinder, Common Rail Direct Injection, Turbocharged with Intercooler

Displacement (cc)

2499

Power kW (hp) @ rpm

100(134) @ 3,600

Torque Nm @ rpm

320 @ 1,800-2,800

Compression Ratio

18.1:1

Bore x Stroke

95.4 x 87.4

No. of Valves

16

Drivetrain

Transmission

5-Speed Manual

Front Differential

Shift On The Fly (N/A on 4x2), Axle Ratio Final Drive (N/A on 4x2)

Rear Differential

Limited Slip Differentoal (LSD) as Standard, Axle Ratio Final Drive 3.909

Fuel Tank Capacity (litres)

76

Chassis

Suspension (Front and Rear)

Front: Highride Coil Spring. Rear: Leaf Spring Overslung. Shock Absorbers: Twin-tube Gas Pressurised (Heavy Duty).

Safety Guards

Skid Plate Guard, Engine Sump Guard, Fuel Tank Guard, Transfer Case Guard (N/A on 4x2)

Tyre Size

205R16C Tubeless All Terrain

Rim Size

6.5J-33x16”Steel

Ground Clearance (mm)

225 (Wading depth 600)

Brakes

Front: Disc Brakes. Rear: Drum.

Steering

Power Assisted

Vehicle Information

Speed Limited

80 km/h

Turning Circle, Curb to Curb (m)

12.8

Load Box Features

4 Tie-down Brackets in Load Box for Load Restraint, 12 Rope Hooks on Load Box (Side and Rear), Cab Protector - Black

Fleet Management System

FMS System Equipped

Gross Vehicle Weights: GVW (Kgs)

2850

Tare Mass (Kg)

1705

Payload (Kg)

1086

Gross Combination Mass (Kgs)

4450

Towing Capacity (Kgs)

Unbraked Trailer: 750

Braked Trailer: 2100

Load Box (mm)

Length 2318, Width 1534, Depth 440

Safety, Security, Lighting

Safety Features

Side Impact Protection Bars, 3-Point Inertia Seatbelts, Height Adjustable (x2), 2-Point Front Centre Seat Lap Belt, Seatbelt Reminder, Collapsible Steering Column

Security Features

Transponder Immobiliser System

Interior and Exterior Lighting

Interior Courtesy Lights, Front Fog Lights, Halogen Multi-Reflector Headlights, Headlights “on” warning buzzer, Side Indicator Position (Doors), Rear Tail Lights - Combination Bulb, High Mounted Centre Stop Light

Interior and Exterior

Exterior Features

Radiator Grille Colour in Material Grey, Front Bumper in Body Colour, Rear Bumper in Material Grey, Exterior Door Handle Colour in Material Black, Exterior Mirror Colour in Material Black, Manual Folding Exterior Mirrors, Mudflaps

Interior Features

Standard Gear Knob Trim, Split Bench Front Seats Configuration, Seat Trim in Canvas, Floor Trim Vinyl, Driver Footrest, Manual Air Conditioner, 12-V Auxiliary Power Supply, Door Trim with Storage Pockets and Integrated Cup Holders, Remote Fuel Flap, Fixed Rear Window, with no Defogger, Manual Windows

Infotainment

Infotainment Features

Radio Tuner, Front-Loading CD Player, MP3 Functionality and Bluetooth Audio Streaming with Integrated Mobile Hands-Free. Audio Input Terminal: Auxiliary, USB with 2 Speakers.

Why Choose the Isuzu D-Max TFR86?

  • Cost-Effective Operation: Low fuel consumption and affordable maintenance.
  • Reliable Performance: Proven Isuzu engineering for dependable work.
  • Versatile Utility: Adapts to a variety of jobs and industries.
  • Built Tough: Rugged design to withstand heavy use and harsh conditions.

The Isuzu D-Max TFR86 4x2 SC Workhorse is your dependable partner for tough jobs, offering the perfect combination of durability, efficiency, and performance. Whether it’s farming, construction, or logistics, this pickup is built to handle it all.

SECTOR SOLUTIONS

Isuzu D-Max TFR86 1t Payload

Sector Solutions

Agricultural and Farming

  • Ideal for transporting farm produce, fertilizers, and tools between fields and marketplaces.

Construction & Light Haulage

  • Perfect for moving building materials, equipment, and tools to job sites.

Logistics & Delivery

  • Efficiently handles deliveries to retail outlets and distribution centers.

Municipal and Utility Services

  • Suitable for maintenance and utility work, carrying tools and equipment across urban and rural areas.

Command Centre

  • Radio Tuner, Front-Loading CD Player, MP3 Functionality, USB, Auxiliary Input, Bluetooth Audio Streaming with Integrated Mobile Hands-Free for the perfect drive.

The Hi-Ride

  • With an impressive 225mm ground clearance, the Isuzu D-Max TFR86 delivers a smooth, comfortable driving experience on all roads with reduced noise and vibration levels thanks to added insulation and improved door seals.

Nunua Isuzu D-Max yako kwenye Fedha - tunaweza kukusaidia!

95% Financing Offer

Grow Your Business with Isuzu

Available on all Isuzu Trucks, Isuzu Buses, Isuzu Pickups and Isuzu SUVs.

  • Up to 95% Financing
  • Up to Ksh 1,000,000 Million working capital
  • Up to 72 Months repayment period
  • 1-1.5% Appraisal Fee
  • Up to 60 Days Repayment Holiday
KUHESABU FEDHA

Technical Highlights

Upgrade your business with the reliable Isuzu D-Max TFR86 Single Cab Workhorse pickup. Visit Africa Commercial Motor Group (ACMG) to explore financing options, customize your truck, and schedule a test drive today.

Engine Performance

  • Powered by the 4JK1-TC HO diesel engine with 1334 hp @ 2,600 rpm and 320 Nm torque.
  • Euro IV compliant for eco-friendly and efficient operations.

Payload and Dimensions

  • Payload Capacity: Up to 1 ton
  • Cargo Bed Dimensions: Spacious and durable bed for heavy-duty tasks

Fuel Efficiency

  • Renowned for low fuel consumption, making it economical for long-distance and daily operations.

Safety and Comfort

  • Hi-ride Suspension
  • Side Impact Protection Bars
  • Comfortable seating with supportive design for long drives
