The Isuzu GXZ60U offers flexibility, power and strength to make it unmatched for the different missions of our customers. Agility and tight turning circles make it perfect truck for city centre jobs. It is stable and secure for inter city transport at commercial speeds on highways and it is ready to take on demanding roads with it's robust structure.

Submit your request on our easy form and a member of ACMG Sales Support team will then be in touch to confirm your details and ensure everything is processed quickly and correctly for your high performance Isuzu GXZ60U 52-ton heavy-duty 6x4 prime mover.

We work with all the major banks and ensure your finance application is seamless with guidance to provide the correct supporting documents ensuring fast turn arounds getting your Isuzu GXZ60U 6x4 heavy-duty prime mover on the road.

F-SERIES HEAVY-DUTY TRUCK

Isuzu GXZ60U 6x4 Prime Mover Specifications

6x4

Drive Configuration

52,000

Gross Combination Mass (GCM) (KG)

254 (345) @ 2,000

Max Output kW (hp) @ rpm

+Expand / Collapse Selection

Engine

Engine model

6NX1-TCS

Emission

Euro II

Type

Diesel 6-cylinder, Common Rail Turbocharged with Inter cooler

Displacement (cc)

7790

Power kW (hp) @ rpm

254(345) @ 2,000

Torque Kgm (Nm) @ rpm

135 (1323) @ 1,300

Pre-Air Cleaner & High Air Intake Pipe

Standard Equipment

Fuel Water Sedimentors

Standard Equipment

Heavy Duty Radiator

Standard Equipment

Drivetrain

Transmission

ZF9S1310, TD 9-speed

Final Drive Ratio (:1)

5.125

Clutch

Type: Dry Single Plate

Operation: Hydraulic Control

Clutch Diameter (mm/inch)

430/17’’

Fuel Tank Capacity (litres)

370

Chassis

Suspension

Front: Multi Leaf Spring Shock Absorbers - Double Acting and Stabiliser Bar. Rear: Multi Leaf Spring with Helper Spring

Tyre Size

315/80R22.5 Tubeless

Rim Size

9x22.5

Brakes

System: Full Air. Air Dryer: Equipped. Front & Rear: Drum. Parking Brake: Rear Wheel Parking. Auxiliary: Compression Release Engine Brake. ABS: Standard

Steering

Power Assisted

Vehicle Information

Speed Limited

80 km/h

Cab

Tilt Cabin Construction. Sleeper Cab. Laminated Curved Windshield. 3 point x 2 for driver & Assistant, 2 Point x 1 for Center Seat. AM/FM Radio. Equipped with Manual Levelling Headlamp Switch, Cab Tilt Switch and Warning Light.

Fleet Management System

FMS System Equipped

Gross Vehicle Weights: GVW (Kgs)

27300

Gross Combination Mass: GCM (Kgs)

52500

Front Axle Weight (Kg)

Gross Allowable Weight (Kg) 7500

Reverse Elliot I-Beam

Rear Axle Weight (Kg)

Gross Allowable Weight (Kg) 25000

Single Banjo, Full Floating, Integral Shaft & Drive Flange

Cab Chassis Mass (Kgs)

7150

Gradeabilty %

49 (approx)

Why Choose the Isuzu GXZ 6x4 Prime Mover?

  • Heavy-Duty Performance: Powerful engine and robust transmission for reliable long-distance hauling.

  • Driver Comfort: Spacious sleeper cab and ergonomic seating for reduced driver fatigue.

  • Fuel Efficiency: Advanced turbocharger system and high-capacity fuel tank minimize downtime and refueling.

  • Reliability: Engineered to handle tough road conditions with minimal maintenance.

  • Versatile Applications: From industrial freight to bulk cargo, this prime mover excels in every application.

The Isuzu GXZ 6x4 Prime Mover sets the standard for heavy-duty transport across Kenya and beyond. Its powerful performance, driver-centric design, and reliability make it the top choice for logistics and long-haul freight operations.

SECTOR SOLUTIONS

Isuzu GXZ 6x4 52t GCM Prime Mover

Sector Solutions

Long Distance Freight

  • Ideal for logistics companies moving heavy goods between major cities like Nairobi, Mombasa, and Kisumu.

Cross-Border Haulage

  • Reliable for cross-border operations to Uganda, Tanzania, and beyond, ensuring consistent performance over extended routes.

Industrial Goods Transport

  • Suited for moving large machinery and industrial products, such as steel coils or heavy equipment.

Bulk Cargo & Container

  • Perfect for containerized freight and bulk cargo, maximizing efficiency with high payload capacity.

Power to Deliver

  • The future is moving to more efficient engines with low displacements and high torque. Our Isuzu intercooled turbo-diesel 6-cylinder powerplant delivers just that. The 345HP punches out 1323Nm of torque featuring reliability and serious power.

Daily Inspection Made Easy

  • The Isuzu GXZ 6x4 52t heavy-duty prime mover offers an easy access front panel that houses the daily inspection and maintenance points that are protected via an interlock and can only be released from inside the cabin for safety.

Nunua Isuzu GXZ60U yako kwenye Fedha - tunaweza kukusaidia!

95% Financing Offer

Grow Your Business with Isuzu

Available on all Isuzu Trucks, Isuzu Buses, Isuzu Pickups and Isuzu SUVs.

  • Up to 95% Financing

  • Up to Ksh 1,000,000 Million working capital

  • Up to 72 Months repayment period

  • 1-1.5% Appraisal Fee

  • Up to 60 Days Repayment Holiday

KUHESABU FEDHA

Technical Highlights

Take your logistics operations to the next level with the Isuzu GXZ 6x4 Prime Mover. Visit Africa Commercial Motor Group (ACMG) to explore financing options, customize your truck, and schedule a test drive.

Engine Performance

  • Engine: 6NX1-TCS Diesel, 6-cylinder, Common Rail Turbocharged with Intercooler

  • Displacement: 7,790 cc

  • Power Output: 345 hp @ 2,000 rpm

  • Torque: 1,323 Nm @ 1,300 rpm

  • Transmission: ZF9S1310, 9-speed manual with crawler gear for improved traction

  • Fuel Tank Capacity: 370 liters

Chassis and Suspension

  • Axle Layout: 6x4 for superior traction and load capacity

  • Front Suspension: Multi-leaf spring with double-acting shock absorbers

  • Rear Suspension: Multi-leaf spring with helper spring for enhanced stability

  • Braking System: Full air brakes with ABS and compression release engine brake

Driver Comfort and Safety

  • Cabin: Tilt cabin with sleeper cab for long-haul comfort

  • Safety Features: ABS, compression release engine brake, and robust seat belts

  • Comfort Features: Air suspension driver seat, tilt and telescopic power steering, AM/FM radio

Safety and Comfort

  • Heavy-duty radiator and fuel water sedimentors for enhanced performance and longevity.

  • Tubeless tires and semi-elliptical alloy steel leaf springs ensure durability on varying road conditions.
